Name: Freight Data NHFN Primary Highway Freight System

Display Field: Sign_Name1

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The National Highway Freight Network (NHFN) consists of four components: 1) Primary Highway Freight System (PHFS): this is a network of highways identified as the most critical highway portions of the U.S. freight transportation system determined by measurable and objective national data; 2) Other Interstate portions not on the PHFS: these highways consistof the remaining portion of Interstate roads not included in the PHFS; 3)Critical Rural Freight Corridors (CRFCs): these are public roads not in an urbanized area which provide access and connection to the PHFS and the Interstate with other important ports, public transportation facilities, or other intermodal freight facilities; 4) Critical Urban Freight Corridors (CUFCs):these are public roads in urbanized areas which provide access and connection to the PHFSand the Interstate with other ports, public transportation facilities, or other intermodal transportation facilities. FHWA designates the PHFS, while states and in certain cases, Metropolitan Planning Organizations (MPOs), are responsible for designating public roads for the CRFCs and CUFCs in accordance with U.S.C Title 23, Section 167. This GIS dataset provides an inventory of the PHFS and Non-PHFS Interstates, reflecting the 2022 redesignation by the FHWA. The original GIS shapefiles were acquired through FHWA’s National Highway Freight Network Tool in 2023: https://usdot.maps.arcgis.com/apps/webappviewer/index.html?id=c4c0fdef029a4093b169e493e1883988

Copyright Text: WSDOT Rail, Freight and Ports Division

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.3705270947284298E7
YMin: 5711135.353357336
XMax: -1.3019575107529445E7
YMax: 6278748.360327387
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [55, 58, 54, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Year_Record ( type: esriFieldTypeString, alias: Year_Record, length: 50 )
• SnapshotDate ( type: esriFieldTypeDate, alias: SnapshotDate, length: 8 )
• State_ID ( type: esriFieldTypeString, alias: State_ID, length: 3 )
• RouteIdentifier ( type: esriFieldTypeString, alias: RouteIdentifier, length: 50 )
• BeginAccumulatedRouteMile ( type: esriFieldTypeSingle, alias: BeginAccumulatedRouteMile )
• EndAccumulatedRouteMile ( type: esriFieldTypeSingle, alias: EndAccumulatedRouteMile )
• Sign1 ( type: esriFieldTypeString, alias: Sign1, length: 4 )
• Sign_Type1 ( type: esriFieldTypeString, alias: Sign_Type1, length: 2 )
• Sign_Name1 ( type: esriFieldTypeString, alias: Sign_Name1, length: 4 )
• LocalName ( type: esriFieldTypeString, alias: LocalName, length: 100 )
• NHS ( type: esriFieldTypeInteger, alias: NHS )
• Source ( type: esriFieldTypeString, alias: Source, length: 50 )
• State_Name ( type: esriFieldTypeString, alias: State_Name, length: 25 )
• LengthMile ( type: esriFieldTypeSingle, alias: LengthMile )
• NHFN_Code ( type: esriFieldTypeInteger, alias: NHFN_Code )
• PublishDate ( type: esriFieldTypeDate, alias: PUBLISHDATE, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
